Tyre Size | Ply Rating | Std. Rim | TL/TT | Load Index | Speed Symbol | Max Pressure (kPa) | Max Load (kg) | Section Width (mm) | Over Diameter (mm) | Tread Depth (mm) |
---|---|---|---|---|---|---|---|---|---|---|
11R22.5 | 14 | 8.25 | TL | 144/142 | M | 720 | 2800/2650 | 279 | 1054 | 11 |
11R22.5 | 16 | 8.25 | TL | 146/143 | M | 830 | 3000/2750 | 279 | 1054 | 11 |
11R24.5 | 14 | 8.25 | TL | 146/143 | M | 720 | 3000/2725 | 279 | 1104 | 11 |
11R24.5 | 16 | 8.25 | TL | 149/146 | M | 830 | 3250/3000 | 279 | 1104 | 11 |
285/75R24.5 | 14 | 8.25 | TL | 144/141 | M | 760 | 2800/2575 | 283 | 1050 | 11 |
285/75R24.5 | 16 | 8.25 | TL | 147/144 | M | 830 | 3075/2800 | 283 | 1050 | 11 |
295/75R22.5 | 14 | 9 | TL | 144/141 | M | 760 | 2800/2575 | 298 | 1014 | 11 |
295/75R22.5 | 16 | 9 | TL | 146/143 | M | 830 | 3000/2725 | 298 | 1014 | 11 |
